Our line of exquisite all wood sliding patio doors offer an unprecedented level of class and comfort. Our hand-crafted GoldenWood® Sliding Patio Doors are constructed using only the finest components and provide the perfect balance between engineering excellence and stunning beauty.
TheGoldenWood® Sliding Patio Door is available in both a Traditional (wide French Rails) and a Contemporary (Narrow Rail) design.
GoldenWood® Sliding Patio Doors
Colour Options
Standard Exterior & Interior Species

Pine
Glass Options
Low E Options

Clear | Hard Coat Low E (3) - CTLT*
This is a durable hard-coated low-emissivity glass that provides passive solar gain resulting in year-round cost savings. Used on the 3rd surface it maximizes energy efficiency in the colder Northern region climates, where heating is dominant and the greatest energy concern.
Soft Coat Low E (2) | Clear – STCT*
The soft-coated low-e glass provides solar heat control in moderate to warm climates. The neutral appearance and high level of natural light transmitted makes this glass ideal solution for homes where heating and cooling requirements vary throughout the year.
Hard Coat Low E (2) | Hard Coat Low E (4) - LTLT*
The addition of a 4th surface Low E technology on insulating glass units allows you to improve the performance of a unit by approximately 15-20%. During cold conditions the coating on surface 2 reduces the heat lost from the airspace to the outside and the coating on surface 4 will reflect heat back into the room.
Soft Coat Low E (2) | Hard Coat Low E (4) - STLT*
The addition of a 4th surface Low E technology on insulating glass units allows you to improve the performance of a unit by approximately 15-20%. During warm conditions the coating on surface 2 reflects solar energy outside and the coating on surface 4 will reflect heat back into the room during cold conditions.
*T denotes "fully tempered" glass
Glass Spacer
Warm Edge Technology
Superspacer®

Decorative Glass Options

Obscure
Grille Options
Grille Patterns

Colonial

Muskoka

Victorian

2" Horizontal

Custom
Grilles Between Glass (GBG)

5/16" Narrow Pewter

5/16" Narrow Brass

5/8" Standard Flat

3/4" Georgian
5/8" Standard Flat & 3/4" Georgian available in:

Golden White

Taupe

Golden Sable

Black
Split finish also available in 5/8" Standard Flat & 3/4" Georgian.
Simulated Divided Lite (SDL)

1" Exterior SDL

2" Exterior Mullion

1" Interior SDL

2" Interior Mullion
Wood Removable

1" Removable Profile
Available in:

Pine
Hardware Options

White

Black

Brass

Antique Brass

Oil Rubbed Bronze

Brushed Nickel

Bright Chrome

Western Pewter
Optional Accessories
Exterior Brickmould

2" Standard Brickmould
Security Options

Optional Footbolt

Optional Security Bar
Sizes & Shapes
Contemporary Sliding Patio Door

Traditional Sliding Patio Door

“R” Denotes the sliding panel, as viewed from the exterior of the door. All “RF” doors shown are also available as “FR” doors.
Performance
Golden Window Products are manufactured and pre-assembled to conform to AAMA/WDMA/CSA101/I.S.2/A440-08, “NAFS - North American Fenestration Standard / Specification for Windows, Doors, and Skylights” and CSA A440S1-09, “Canadian
Supplement to AAMA/WDMA/CSA101/I.S.2/A440-08, NAFS - North American Fenestration Standard / Specification for Windows, Doors, and Skylights” and the applicable requirements of the 2012 Ontario Building Code.
Clad/Wood Sliding Patio Door
Class LC-PG30: Size tested 2412 x 2423 mm (94.96 x 95.39)-Type SD
Positive Design Pressure = 1440 Pa (30 psf)
Negative Design Pressure = -1440 Pa (-30 psf)
Water Penetration Resistance Test Pressure = 400 Pa (8 psf)
Canadian Air Infiltration/Exfiltration = A3 Level
Clad/Wood Sliding Patio Door Sidelite
Positive Design Pressure = 1440 Pa (30 psf)
Negative Design Pressure = -1440 Pa (-30 psf)
Water Penetration Resistance Test Pressure = 510 Pa (11 psf)
Canadian Air Infiltration/Exfiltration = A3 Level
Appropriate selection of Golden Window’s windows, doors, and accessories which conform to all applicable laws, ordinances, building codes and safety requirements is the sole responsibility of the architect, building owner and/or contractor. All risks related to building design and construction, maintenance, or the installation and use of Golden Windows Limited products shall be assumed by Buyer and/or User.
For Professionals
Contemporary Vertical Section

Contemporary Horizontal Section

Traditional Vertical Section

Head Section

Sill Section
Traditional Horizontal Section

Drawings are not to scale.
